Cabinet Specifications

Standard Construction
At a glance:
  • Particleboard construction.
  • 5/8" Hardwood dovetail drawers.
  • 3/4" particleboard shelves with light maple laminate and matching PVC edge banding.
  • Laminate interior and exterior sides.
View PDF Booklet
alttext

6-way Adjustable Hinges are heavy duty, self closing, and concealed within the cabinet door and frame.

alttext

Wall & Base Backs are 1/2” particleboard with light maple laminate. Wall backs are stapled and glued into rabeted ends.

alttext

Drawer Slides are 75 lb load rated, epoxy coated metal slides. Upgrades to 100 lb full extension and soft close full extension are available.

alttext

Wall & Base Sides are 1/2" particleboard with light maple laminate interior and laminate exterior that matches door and frame color.

alttext

5/8" Hardwood dovetail Drawers feature four sided construction and captive ¼" matching MDF laminate bottom.

alttext

Base Bottoms are 1/2" particleboard with light maple laminate interiors. Bottoms are hot melt glued into dados on all four sides.

alttext

Door & Drawer fronts are assembled with kiln-dried solid American hardwood.

alttext

Wall Tops & Bottoms are 1/2" particleboard with light maple laminate, hot melt glued into dados on all four sides.

alttext

Edgebanded Shelves are made with 3/4" thick laminate particle board with a clean edgebanded finish.

alttext

Countertop Attachment Rails are 1/2" particleboard. Rails are hot melt glued into face frame, sides, and cabinet back.

alttext

Face Frame Stile and Rails are 3/4" thick and 1 ½" wide kiln-dried hardwood. Frames are assembled under pressure with pocket screws.

alttext

Standard Toe Kicks measure 3 ½" deep by 4 ½" tall. 9" Handicap toe kick available on most cabinet models.

Ply-A Construction (all plywood)
At a glance:
  • Plywood construction.
  • 5/8" Hardwood dovetail drawers with 1/4" plywood bottoms.
  • 3/4" Plywood shelves with light maple laminate and matching PVC edge banding.
  • Laminate interior and exterior sides.
View PDF Booklet
alttext

6-way Adjustable Hinges are heavy duty, self closing, and concealed within the cabinet door and frame.

alttext

Wall & Base Backs are 1/2" plywood with light maple laminate. Wall backs are stapled and glued into rabeted ends.

alttext

Drawer Slides are 75 lb load rated, epoxy coated metal slides. Upgrades to 100 lb full extension and soft close full extension are available.

alttext

Wall & Base Sides are 1/2" plywood with light maple laminate interior and laminate exterior that matches door and frame color.

alttext

5/8" Hardwood dovetail Drawers feature four sided construction and ¼" matching plywood bottom.

alttext

Base Bottoms are 1/2" plywood with light maple laminate interiors. Bottoms are hot melt glued into dados on all four sides.

alttext

Door & Drawer fronts are assembled with kiln-dried solid American hardwood.

alttext

Wall Tops & Bottoms are 1/2" plywood with light maple laminate, hot melt glued into dados on all four sides.

alttext

Plywood Edgebanded Shelves are made with 3/4" thick laminate particle board with a clean edgebanded finish.

alttext

Countertop Attachment Rails are 1/2" plywood. Rails are hot melt glued into face frame, sides, and cabinet back.

alttext

Face Frame Stile and Rails are 3/4" thick and 1 ½" wide kiln-dried hardwood. Frames are assembled under pressure with pocket screws.

alttext

Standard Toe Kicks measure 3 ½" deep by 4 ½" tall. 9" Handicap toe kick available on most cabinet models.

Max Construction
At a glance:
  • Plywood construction.
  • 5/8" Hardwood dovetail drawers.
  • 3/4" Plywood shelves with light maple laminate and matching PVC edge banding.
  • ACQ pressure treated solid toe kick.
  • Laminate interior and exterior sides.
View PDF Booklet
alttext

6-way Adjustable Hinges are heavy duty, self closing, and concealed within the cabinet door and frame.

alttext

Wall & Base Backs are 1/2" plywood with light maple laminate. Wall backs are stapled and glued into rabeted ends.

alttext

Drawer Slides are 75 lb load rated, epoxy coated metal slides. Upgrades to 100 lb full extension and soft close full extension are available.

alttext

Wall & Base Sides are 1/2" plywood with light maple laminate interior and laminate exterior that matches door and frame color.

alttext

5/8" Hardwood dovetail drawers feature four sided construction and captive 1/4" matching plywood bottom.

alttext

Base Bottoms are 1/2" plywood with light maple laminate interiors. Bottoms are hot melt glued into dados on all four sides.

alttext

Door & Drawer fronts are assembled with kiln-dried solid American hardwood.

alttext

Wall Tops & Bottoms are 1/2" plywood with light maple laminate, hot melt glued into dados on all four sides

alttext

Plywood Edgebanded Shelves are made with 3/4" thick laminate particle board with a clean edgebanded finish.

alttext

Countertop Attachment Rails are 1/2" plywood. Rails are hot melt glued into face frame, sides, and cabinet back.

alttext

Face Frame Stile and Rails are 3/4" thick and 1 ½" wide kiln-dried hardwood. Frames are assembled under pressure with pocket screws.

alttext

ACQ Pressure Treated Toe Kicks measure 3 ½" deep by 4 ½" tall. 9" Handicap toe kick available on most cabinet models.

Ultimate Construction
At a glance:
  • Plywood construction.
  • 5/8" Hardwood dovetail drawers.
  • 3/4" Plywood shelves with light maple laminate and matching PVC edge banding.
  • ACQ pressure treated base perimeter and toe kick is 2" x 6" solid lumber.
  • Applicable for HUD Section 42, HUD Section 8, and USDA RHS Public Housing Projects.
  • Laminate interior and exterior sides.
View PDF Booklet
alttext

6-way Adjustable Hinges are heavy duty, self closing, and concealed within the cabinet door and frame.

alttext

Wall & Base Backs are 1/2" plywood with light maple laminate. Wall backs are stapled and glued into rabeted ends.

alttext

Drawer Slides are 75 lb load rated, epoxy coated metal slides. Upgrades to 100 lb full extension and soft close full extension are available.

alttext

Wall & Base Sides are 1/2" plywood with light maple laminate interior and laminate exterior that matches door and frame color.

alttext

5/8" Hardwood dovetail drawers feature four sided construction and captive 1/4" matching plywood bottom.

alttext

Base Bottoms are 1/2" plywood with light maple laminate interiors. Bottoms are hot melt glued into dados on all four sides.

alttext

Door & Drawer fronts are assembled with kiln-dried solid American hardwood.

alttext

Wall Tops & Bottoms are 1/2" plywood with light maple laminate, hot melt glued into dados on all four sides

alttext

Plywood Edgebanded Shelves are made with 3/4" thick laminate particle board with a clean edgebanded finish.

alttext

Countertop Attachment Rails are 1/2" plywood. Rails are hot melt glued into face frame, sides, and cabinet back.

alttext

Face Frame Stile and Rails are 3/4" thick and 1 ½" wide kiln-dried hardwood. Frames are assembled under pressure with pocket screws.

alttext

ACQ Pressure Treated Base Perimeter is made from 2" x 6" solid lumber, and measures 3 ½" deep by 4 ½" tall. 9" Handicap toe kick available on most cabinet models.

2/01/2020. Specifications subject to change without prior notice.
